LH-GF-PRO (2+1) configuration overview
The LH-GF-PRO (2+1) is a six-seat lithium electric golf cart with a 72V / 150Ah battery and a 7.5 kW AC motor. Its 3,950 × 1,380 × 1,986 mm body gives buyers a specific configuration to compare with the standard LH-6GF.
Compare the model options
The standard LH-6GF lists a 72V / 100Ah battery and 3.5 kW motor. Compare battery capacity, motor output, seating layout and vehicle dimensions; the Pro designation does not mean that every specification is the same.
Related models: LH-6GF. Compare the complete product range.
Technical specifications
| Parameter | LH-GF-PRO (2+1) |
|---|---|
| Brand | SUNRISTECH |
| Controller | 72V / 400A Intelligent Controller |
| Battery | 72V / 150Ah Lithium Battery |
| Motor | 7.5 kW AC Motor |
| Charger | Fully Enclosed Intelligent On-Board Charger |
| Charging Time | 8-10 Hours (at 80% Depth of Discharge) |
| Charging Input Voltage | 220V |
| Dimensions (L × W × H) | 3950 x 1380 x 1986 mm |
| Net Weight | 634 kg |
| Maximum payload | 450 kg |
| Front / Rear Track | 980 / 1050 mm |
| Wheelbase | 3150 mm |
| Min. Ground Clearance | 190 mm |
| Seating Capacity | 6 Seats |
| Max. Speed | 28 km/h |
| Max. Gradeability | 30% |
| Min. Turning Radius | 6 m |
| Range | 60-80 km |
| Braking Distance | <=5 m |
| Seats | White or Black Seats / Multiple Colors Available |
| Body Structure | High-Strength Automotive-Grade Body + Steel Frame |
| Instrument Panel | Digital Display: Voltage / Current / Speed / Mileage / Lighting / Turn Signal Indicators |
| Rearview Mirrors | Manually Adjustable Rearview Mirrors |
| Lighting & Signals | Combination Headlights / Turn Signals / Tail Lights / Brake Lights / Electric Horn |
| Audio System | On-Board MP3 Player + Speakers |
| Switches | Start Switch / Lighting & Wiper Combination Switch / Forward-Reverse Switch |
| Doors | None |
| Frame | Steel Frame |
| Steering Wheel | Polyurethane Foam Steering Wheel |
| Drive System | Stepless Electronic Speed Control |
| Steering System | Rack-and-Pinion Steering |
| Front Suspension | Independent Suspension |
| Rear Axle & Suspension | Solid Rear Axle + Heavy-Duty Springs + Hydraulic Shock Absorbers |
| Braking System | Front & Rear Hydraulic Drum Brakes + Dual-Circuit Hydraulic Braking + Parking Brake |
| Wheels & Tires | Aluminum Alloy Wheels + 12-Inch Tubeless Tires |
| Cockpit | Adjustable Seats / Safety Belts |
| Package Gross Weight | 780 kg |
| Package Size | 3860 x 1320 x 1200 mm |
| Container loading reference | 6 PCS / 40HQ; 1 PC / 20GP |
Specifications describe the listed configuration. Range, charging time and performance depend on the battery, load, route and operating conditions. Confirm the final equipment and specification in your quotation.
Configuration and wholesale enquiries
Request LH-GF-PRO (2+1) availability with your quantity, destination and intended use. Tell us any color, branding or equipment requirements. Available options, minimum order and sample terms are confirmed for the selected configuration.
For branding or engineering changes, see our customization service. For model mixes and ongoing supply, visit wholesale and dealer cooperation.
Before confirming your order
- Agree the exact motor, battery, charger and included equipment.
- Confirm seating, vehicle dimensions and the intended operating environment.
- Review packing, freight terms, destination requirements and delivery timing.
- Request the applicable operating documents, warranty terms and support arrangements.
LH-GF-PRO (2+1) buyer questions
Which seating configuration should I choose?
Start with the passenger count and route dimensions. This model lists 6 seats. Compare the standard and Pro layouts where available, then confirm the final seating arrangement.
What should I confirm about charging?
The configuration lists 8-10 Hours (at 80% Depth of Discharge). Confirm battery chemistry, charger input and the available site supply before ordering. Charging time and range depend on the actual battery and operating conditions.
