LH-8GF configuration overview
The SUNRISTECH LH-8GF is a 8-seat electric golf cart with a 72V / 100Ah battery specification and a listed footprint of 4460 × 1250 × 1900 mm. Compare its passenger capacity, turning radius and charging requirements for a resort, leisure property or other managed-site transport project.
Compare the model options
This 8-seat configuration lists a 3.5 kW motor and a 72V / 100Ah battery. Check the 4460 × 1250 × 1900 mm vehicle dimensions against route width, storage space and transport plans. Battery chemistry should be confirmed in the quotation; voltage and capacity alone do not establish that it is lithium.
Related models: LH-6GF. Compare the complete product range.
Technical specifications
| Parameter | LH-8GF |
|---|---|
| Brand | SUNRISTECH |
| Dimensions (L × W × H) | 4460 x 1250 x 1900 mm |
| Controller | 72V / 400A |
| Battery | 72V / 100Ah |
| Motor Power | 3.5 kW |
| Charging Time | 8-10 Hours |
| Range | 80 km |
| Seating Capacity | 8 Persons |
| Curb Weight | 780 kg |
| Max. Speed | 28 km/h |
| Max. Gradeability | 30% |
| Front Track | 1200 mm |
| Rear Track | 1200 mm |
| Min. Turning Radius | 6 m |
| Wheelbase | 3900 mm |
| Min. Ground Clearance | 190 mm |
| Braking Distance | <=5 m |
| Body Structure | High-Strength Automotive-Grade Material |
| Steering System | Rack-and-Pinion Steering |
| Frame | Steel Frame |
| Steering Wheel | Polyurethane Foam Steering Wheel |
| Tires | 205-10 |
| Front Suspension | Independent Suspension |
| Drive System | Stepless Electronic Speed Control |
| Floor | Electrophoretic-Coated Welded Steel Floor |
| Body Material | PP Plastic |
| Suspension | MacPherson Independent Suspension |
| Cockpit | Adjustable Seats / Safety Belts |
| Package Gross Weight | 850 kg |
| Package Size | 4500 x 1320 x 1200 mm |
| Container loading reference | 6 PCS / 40HQ; 1 PC / 20GP |
Specifications describe the listed configuration. Range, charging time and performance depend on the battery, load, route and operating conditions. Confirm the final equipment and specification in your quotation.
Configuration and wholesale enquiries
Request LH-8GF availability with your quantity, destination and intended use. Tell us any color, branding or equipment requirements. Available options, minimum order and sample terms are confirmed for the selected configuration.
For branding or engineering changes, see our customization service. For model mixes and ongoing supply, visit wholesale and dealer cooperation.
Before confirming your order
- Agree the exact motor, battery, charger and included equipment.
- Confirm seating, vehicle dimensions and the intended operating environment.
- Review packing, freight terms, destination requirements and delivery timing.
- Request the applicable operating documents, warranty terms and support arrangements.
LH-8GF buyer questions
Which seating configuration should I choose?
Start with the passenger count and route dimensions. This model lists 8 persons. Compare the standard and Pro layouts where available, then confirm the final seating arrangement.
What should I confirm about charging?
The configuration lists 8-10 Hours. Confirm battery chemistry, charger input and the available site supply before ordering. Charging time and range depend on the actual battery and operating conditions.
