930MAX configuration overview
The 930MAX Classic Electric Mini Roadster has a listed footprint of 3,200 × 1,400 × 900 mm. Its larger dimensions distinguish it from the 930S and 930D, so compare space, packing and seating requirements by model rather than by series name alone.
Compare the model options
The 930MAX is 3,200 mm long, compared with 2,100 mm for the 930S and 2,680 mm for the 991. Review the exact model dimensions before selecting a mixed order or planning display and storage space.
Related models: 930S and 991. Compare the complete product range.
Technical specifications
| Parameter | 930MAX |
|---|---|
| Brand | SUNRISTECH |
| Motor Type | Permanent Magnet Synchronous Brushless Motor |
| Motor Power | 2500W / 72V |
| Body Material | One-Piece Molded Composite Body |
| Chassis structure | Q235 Structural Steel + Laser-Welded Tubular Space Frame |
| Drive System | Rear-Mounted Motor / Rear-Wheel Drive |
| Suspension | Front Double Wishbone / Rear Integral Axle / Hydraulic Shock Absorbers |
| Max. Speed | Up to 80 km/h |
| Starting system | Key Start |
| Battery | 72V / 40Ah Branded Lithium Battery |
| Maximum payload | 280Kg |
| Transmission | Shaft Drive |
| Min Ground Clearance | 90 mm |
| Front Tire Size | 215/40-12 Radial Tires |
| Rear Tire Size | 215/40-12 Radial Tires |
| Braking System | Hydraulic Disc Brakes |
| Parking Brake | Electronic Parking Brake |
| Gear Selection | Forward / Reverse / Low Speed / High Speed |
| Operating Time | Approx. 6–8 Hours |
| Driving Range | Approx. 50 km |
| Lighting System | Headlights / Brake Lights / Turn Signals |
| Charging Time | Standard: 6 Hours / Fast Charge: 1 Hour |
| Net Weight | 330 kg (Four-Seats) |
| Dimensions (L × W × H) | 3200*1400*900mm |
| Seat Configuration | Adjustable Seat + Safety Belt |
| Package Gross Weight | 400kg |
| Package Size | 3300*1500*950mm |
| Container loading reference | 6PCS/40HQ ； 2PCS/20GP |
Specifications describe the listed configuration. Range, charging time and performance depend on the battery, load, route and operating conditions. Confirm the final equipment and specification in your quotation.
Configuration and wholesale enquiries
Request 930MAX availability with your quantity, destination and intended use. Tell us any color, branding or equipment requirements. Available options, minimum order and sample terms are confirmed for the selected configuration.
For branding or engineering changes, see our customization service. For model mixes and ongoing supply, visit wholesale and dealer cooperation.
Before confirming your order
- Agree the exact motor, battery, charger and included equipment.
- Confirm seating, vehicle dimensions and the intended operating environment.
- Review packing, freight terms, destination requirements and delivery timing.
- Request the applicable operating documents, warranty terms and support arrangements.
930MAX buyer questions
Which battery and motor are included?
The listed configuration is 2500W / 72V, with 72V / 40Ah Branded Lithium Battery. Confirm the motor, cooling arrangement, battery and charger together in the quotation.
Can I request a sample or a mixed-model order?
Ask for availability of the 930MAX configuration and provide your model quantities and destination. Sample terms, minimum order, packing and delivery timing are confirmed for the order.
