930S configuration overview
The 930S is the standard configuration in the 930S/930D pair. Its one-piece ABS body and 2,100 mm vehicle length provide a distinct alternative to the larger composite-body retro models.
Compare the model options
The 930S and 930D both list a 2,500 W / 72V motor and a 40 Ah battery. The rear-tire equipment, width and other details differ. Choose by the complete configuration, not by motor output alone.
Related models: 930D. Compare the complete product range.
Technical specifications
| Parameter | 930S |
|---|---|
| Brand | SUNRISTECH |
| Motor Type | Permanent Magnet Synchronous Brushless Motor |
| Motor Power | 2500W / 72V |
| Body Material | One-Piece ABS Plastic Body |
| Chassis structure | Q235 Structural Steel + Laser-Welded Space Frame |
| Drive System | Rear-Mounted Motor + Rear-Wheel Drive |
| Suspension | Double Wishbone Front Suspension / Solid Rear Axle / Coil Springs + Shock Absorbers |
| Max. Speed | Top Speed: Up to 60 km/h |
| Starting system | Key Start |
| Battery | 72V / 40Ah Branded Lithium Battery |
| Maximum payload | 250 kg |
| Transmission | Shaft Drive |
| Min Ground Clearance | 90 mm |
| Front Tire Size | 13 / 5.0 / 6 Vacuum Tires |
| Rear Tire Size | 13 / 5.0 / 6 Vacuum Tires |
| Braking System | Hydraulic Disc Brakes |
| Parking Brake | Electronic Braking |
| Gear Selection | Forward / Reverse / Low Speed / High Speed |
| Operating Time | Approx. 6-8 Hours |
| Driving Range | 50 km Range |
| Lighting System | Headlights / Brake Lights / Turn Signals |
| Charging Time | Standard Charging: 6 Hours / Fast Charging: 1 Hour |
| Net Weight | 195 kg / Single Seat |
| Dimensions (L × W × H) | 2100 x 950 x 680 mm |
| Seat Configuration | Adjustable Seat / Safety Belt |
| Package Gross Weight | 250 kg / Single Seat |
| Package Size | 2200*1100*650mm |
| Container loading reference | 40PCS/40HQ ; 12PCS/20GP |
Specifications describe the listed configuration. Range, charging time and performance depend on the battery, load, route and operating conditions. Confirm the final equipment and specification in your quotation.
Configuration and wholesale enquiries
Request 930S availability with your quantity, destination and intended use. Tell us any color, branding or equipment requirements. Available options, minimum order and sample terms are confirmed for the selected configuration.
For branding or engineering changes, see our customization service. For model mixes and ongoing supply, visit wholesale and dealer cooperation.
Before confirming your order
- Agree the exact motor, battery, charger and included equipment.
- Confirm seating, vehicle dimensions and the intended operating environment.
- Review packing, freight terms, destination requirements and delivery timing.
- Request the applicable operating documents, warranty terms and support arrangements.
930S buyer questions
Which battery and motor are included?
The listed configuration is 2500W / 72V, with 72V / 40Ah Branded Lithium Battery. Confirm the motor, cooling arrangement, battery and charger together in the quotation.
Can I request a sample or a mixed-model order?
Ask for availability of the 930S configuration and provide your model quantities and destination. Sample terms, minimum order, packing and delivery timing are confirmed for the order.
