L-MINI-1 configuration overview
The L-MINI-1 is the two-seat MINI configuration in the L series. It uses rear-wheel electric drive, a 72V / 40Ah lithium battery and a motor rated at 2.5 kW, with 7.5 kW peak output listed separately. The MINI is not a four-wheel-drive model.
Compare the model options
Compared with the MAX, this MINI has two seats and a smaller 2,000 × 1,100 × 1,150 mm body. Its RWD configuration and battery capacity should be assessed against the intended route and passenger load.
Related models: L-MAX-1. Compare the complete product range.
Technical specifications
| Parameter | L-MINI-1 |
|---|---|
| Brand | SUNRISTECH |
| Motor Type | Air-Cooled Permanent Magnet Synchronous Motor |
| Motor Power | Rated Power: 2.5 kW / Peak Power: 7.5 kW |
| Body Material | One-Piece Composite Fiber Body |
| Chassis structure | Q235 Structural Steel + Laser-Welded Space Frame |
| Drive System | Rear-Mounted RWD / Electric Drive |
| Suspension | Front & Rear Four-Link Suspension |
| Max. Speed | Up to 60 km/h |
| Starting system | Key Start |
| Battery | 72V / 40Ah Branded Lithium Battery |
| Maximum payload | 280 kg |
| Transmission | Shaft Drive |
| Max. Gradeability | 0.5 |
| Min. Ground Clearance | 200 mm |
| Front / Rear Tires | 18×6-10 Off-Road Tires |
| Braking System | Front & Rear Hydraulic Ventilated Disc Brakes |
| Shock Absorbers | Four-Wheel Hydraulic Shock Absorbers |
| Parking Brake | Electronic Parking Brake |
| Drive Modes | Forward / Reverse / Low Speed / Medium Speed / High Speed |
| Runtime | Approx. 6–8 Hours |
| Range | 50 km (Typical Operating Conditions) |
| Lighting | Headlights / Brake Lights / Turn Signals |
| Seating Layout | 1 Row / 2 Seats |
| Charging Time | Standard: 6 Hours / Fast: 1 Hour |
| Net Weight | 180 kg |
| Dimensions (L × W × H) | 2000x1100x1150 mm |
| Cockpit | Adjustable Seats / Safety Belts |
| Package Gross Weight | 260kg |
| Package Size | 2000x1100x1150 mm |
| Container loading reference | 24PCS/40HQ ；8PCS/20GP |
Specifications describe the listed configuration. Range, charging time and performance depend on the battery, load, route and operating conditions. Confirm the final equipment and specification in your quotation.
Configuration and wholesale enquiries
Request L-MINI-1 availability with your quantity, destination and intended use. Tell us any color, branding or equipment requirements. Available options, minimum order and sample terms are confirmed for the selected configuration.
For branding or engineering changes, see our customization service. For model mixes and ongoing supply, visit wholesale and dealer cooperation.
Before confirming your order
- Agree the exact motor, battery, charger and included equipment.
- Confirm seating, vehicle dimensions and the intended operating environment.
- Review packing, freight terms, destination requirements and delivery timing.
- Request the applicable operating documents, warranty terms and support arrangements.
L-MINI-1 buyer questions
Is this model four-wheel drive?
This MINI specification lists RWD. Choose a MAX model for an AWD configuration and review its separate specifications.
How are rated and peak power different?
The listed motor specification is Rated Power: 2.5 kW / Peak Power: 7.5 kW. Use the rated output and intended duty cycle when comparing models; peak output is a separate specification.
