F40 configuration overview
The F40 Electric Junior Car combines its model-specific body with a 72V electric drivetrain. Junior Car is the product-family name; confirm driver fit, seating and operating requirements for the intended users.
Compare the model options
The Pro version lists a 4,000 W water-cooled motor and a 72V / 75Ah battery. This standard model uses the 2,500 W motor and 40 Ah battery. Select the specification that fits your operating plan rather than assuming the versions are interchangeable.
Related models: F40 Pro. Compare the complete product range.
Technical specifications
| Parameter | F40 |
|---|---|
| Brand | SUNRISTECH |
| Motor Type | Permanent Magnet Synchronous Brushless Motor |
| Motor Power | 2500W / 72V |
| Body Material | One-Piece Molded Composite Body |
| Chassis structure | Q235 Structural Steel + Laser-Welded Tubular Space Frame |
| Drive System | Rear-Mounted Motor / Rear-Wheel Drive |
| Suspension | Front Double Wishbone / Rear Integral Axle / Hydraulic Shock Absorbers |
| Max. Speed | Up to 80 km/h |
| Starting system | Key Start |
| Battery | 72V / 40Ah Branded Lithium Battery |
| Maximum payload | 250 kg |
| Transmission | Shaft Drive |
| Min Ground Clearance | 90 mm |
| Front Tire Size | 165/45-R10 Radial Tires |
| Rear Tire Size | 165/45-R10 Radial Tires |
| Braking System | Hydraulic Disc Brakes |
| Parking Brake | Electronic Parking Brake |
| Gear Selection | Forward / Reverse / Low Speed / High Speed |
| Operating Time | Approx. 6-8 Hours |
| Driving Range | Approx. 50 km |
| Lighting System | Headlights / Brake Lights / Turn Signals |
| Charging Time | Standard: 6 Hours / Fast Charge: 1 Hour |
| Net Weight | 240 kg (Single-Seat) / 250 kg (Two-Seat) |
| Dimensions (L × W × H) | 2680 x 1150 x 750 mm |
| Seat Configuration | Adjustable Seat + Safety Belt |
| Package Gross Weight | 290 kg /Single-Seat; 300 kg /Two-Seat |
| Package Size | 2700*1150*700mm |
| Container loading reference | 24PCS/40HQ ; 12PCS/20GP |
Specifications describe the listed configuration. Range, charging time and performance depend on the battery, load, route and operating conditions. Confirm the final equipment and specification in your quotation.
Configuration and wholesale enquiries
Request F40 availability with your quantity, destination and intended use. Tell us any color, branding or equipment requirements. Available options, minimum order and sample terms are confirmed for the selected configuration.
For branding or engineering changes, see our customization service. For model mixes and ongoing supply, visit wholesale and dealer cooperation.
Before confirming your order
- Agree the exact motor, battery, charger and included equipment.
- Confirm seating, vehicle dimensions and the intended operating environment.
- Review packing, freight terms, destination requirements and delivery timing.
- Request the applicable operating documents, warranty terms and support arrangements.
F40 buyer questions
Which battery and motor are included?
The listed configuration is 2500W / 72V, with 72V / 40Ah Branded Lithium Battery. Confirm the motor, cooling arrangement, battery and charger together in the quotation.
Can I request a sample or a mixed-model order?
Ask for availability of the F40 configuration and provide your model quantities and destination. Sample terms, minimum order, packing and delivery timing are confirmed for the order.
